Digital Cinema Initiatives, LLC (DCI) is a consortium of major motion picture studios, formed to establish specifications for a common systems architecture for digital cinema systems. The organization was formed in March 2002 by Metro-Goldwyn-Mayer, Paramount Pictures, Sony Pictures, 20th Century Studios, Universal Studios, Walt Disney Studios and Warner Bros. Entertainment The primary purpose of DCI is to establish and document specifications for an open architecture for digital cinema that ensures a uniform and high level of technical performance, reliability and quality. By establishing a common set of content requirements, distributors, studios, exhibitors, d-cinema manufacturers and vendors can be assured of interoperability and compatibility. Because of the relationship of DCI to many of Hollywood's key studios, conformance to DCI's specifications is considered a requirement by software developers or equipment manufacturers targeting the digital cinema market. == Specification == On July 20, 2005, DCI released Version 1.0 of its "Digital Cinema System Specification", commonly referred to as the "DCI Specification". The document describes overall system requirements and specifications for digital cinema. Between March 28, 2006, and March 21, 2007, DCI issued 148 errata to Version 1.0. DCI released Version 1.1 of the DCI Specification on April 12, 2007, incorporating the previous 148 errata into the DCI Specification. On April 15, 2007, at the annual NAB Digital Cinema Summit, DCI announced the new version, as well as some future plans. They released the "Stereoscopic Digital Cinema Addendum" to begin to establish 3-D technical specifications in response to the popularity of 3-D stereoscopic films. It was also announced "which studios would take over the leadership roles in DCI after the current leadership term expires at the end of September." Subsequently, between August 27, 2007, and February 1, 2008, DCI issued 100 errata to Version 1.1. So, DCI released Version 1.2 of the DCI Specification on March 7, 2008, again incorporating the previous 100 errata into the specification document. An additional 96 errata were issued by August 30, 2012, so a revised Version 1.2 incorporating those additional errata was approved on October 10, 2012. DCI approved DCI Specification Version 1.3 on June 27, 2018, integrating the 45 errata issued to the previous version into a new document. On July 20, 2020, fifteen years to the day after Version 1.0, DCI issued a new DCI Specification Version 1.4 that assimilated 29 errata issued since Version 1.3. On October 13, 2021, DCI approved a new DCI Specification Version 1.4.1 that integrated the 23 errata that had been issued to DCI Specification Version 1.4. For the convenience of users, DCI also created an online HTML version of DCI Specification, Version 1.4.1. Due to the HTML conversion process, the footnotes in the DCSS now appear as endnotes. The PDF version contains pagination and page numbers whereas the HTML version does not. DCI Specification Version 1.4.2, dated June 15, 2022, includes revisions and refinements respecting Object-Based Audio Essence (OBAE), also known as Immersive Audio Bitstream (IAB). Version 1.4.2 also implements post-show log record collection utilizing SMPTE 430-17 SMS-OMB Communications Protocol Specification. Additionally, Version 1.4.2 incorporated two prior addenda: the Digital Cinema Object-Based Audio Addendum, dated October 1, 2018 and the Stereoscopic Digital Cinema Addendum, Version 1.0, dated July 11, 2007. Users using Version 1.4.2 no longer need to refer to the separate addenda. Previous DCSS versions are archived on the DCI web site. Based on many SMPTE and ISO standards, such as JPEG 2000-compressed image and "broadcast wave" PCM/WAV sound, the DCI Specification explains the route to create an entire Digital Cinema Package (DCP) from a raw collection of files known as the Digital Cinema Distribution Master (DCDM), as well as the specifics of its content protection, encryption, and forensic marking. The DCI Specification also establishes standards for the decoder requirements and the presentation environment itself, such as ambient light levels, pixel aspect and shape, image luminance, white point chromaticity, and those tolerances to be kept. Even though it specifies what kind of information is required, the DCI Specification does not include specific information about how data within a distribution package is to be formatted. Formatting of this information is defined by the Society of Motion Picture and Television Engineers (SMPTE) digital cinema standards and related documents. == Image and audio capability overview == === 2D image === 2048×1080 (2K) at 24 frame/s or 48 frame/s, or 4096×2160 (4K) at 24 frame/s In 2K, for Scope (2.39:1) presentation 2048×858 pixels of the imager is used In 2K, for Flat (1.85:1) presentation 1998×1080 pixels of the imager is used In 4K, for Scope (2.39:1) presentation 4096×1716 pixels of the imager is used In 4K, for Flat (1.85:1) presentation 3996×2160 pixels of the imager is used 12 bits per color component (36 bits per pixel) via dual HD-SDI (encrypted) 10 bits only permitted for 2K at 48 frame/s CIE XYZ color space, gamma-corrected TIFF 6.0 container format (one file per frame) JPEG 2000 compression From 0 to 5 or from 1 to 6 wavelet decomposition levels for 2K or 4K resolutions, respectively Compression rate of 4.71 bits/pixel (2K @ 24 frame/s), 2.35 bits/pixel (2K @ 48 frame/s), 1.17 bits/pixel (4K @ 24 frame/s) 250 Mbit/s maximum image bit rate === Stereoscopic 3D image === 2048×1080 (2K) at 48 frame/s - 24 frame/s per eye (4096×2160 4K not supported) In 2K, for Scope (2.39:1) presentation 2048×858 pixels of the imager is used In 2K, for Flat (1.85:1) presentation 1998×1080 pixels of the imager is used Optionally, in the HD-SDI link only: 12 bit color, YCxCz 4:2:2 (i.e. chroma subsampling in XYZ space), each eye in separate stream === Audio === 24 bits per sample, 48 kHz or 96 kHz Up to 16 channels WAV container, uncompressed PCM DCI has additionally published a document outlining recommended practice for High Frame Rate digital cinema. This document discloses the following proposed frame rates: 60, 96, and 120 frames per second for 2D at 2K resolution; 48 and 60 for stereoscopic 3D at 2K resolution; 48 and 60 for 2D at 4K resolution. The maximum compressed bit rate for support of all proposed frame rates should be 500 Mbit/s. == Related information == The idea for DCI was originally mooted in late 1999 by Tom McGrath, then COO of Paramount Pictures, who applied to the U.S. Department of Justice for anti-trust waivers to allow the joint cooperation of all seven major motion picture studios. Universal Pictures made one of the first feature-length DCPs created to DCI specifications, using their film Serenity. Although it was not distributed theatrically, it had one public screening on November 7, 2005, at the USC Entertainment Technology Center's Digital Cinema Laboratory in the Pacific Theatre, Hollywood. Inside Man (2006) was Universal's first DCP commercial release, and, in addition to 35mm film distribution, was delivered via hard drive to 20 theatres in the United States along with two trailers. The Academy Film Archive houses the Digital Cinema Initiatives, LLC Collection, which includes film and digital elements from DCI's Standard Evaluation Material (StEM), a 12-minute production shot on 35mm and 65mm film, created for vendors and standards organizations to test and evaluate image compression and digital projection technologies.
SPL notation
SPL (Sentence Plan Language) is an abstract notation representing the semantics of a sentence in natural language. In a classical Natural Language Generation (NLG) workflow, an initial text plan (hierarchically or sequentially organized factoids, often modelled in accordance with Rhetorical Structure Theory) is transformed by a sentence planner (generator) component to a sequence of sentence plans modelled in a Sentence Plan Language. A surface generator can be used to transform the SPL notation into natural language sentences. Probably the most widely used SPL language used today (2022) is AMR (Abstract Meaning Representation, see there for further references), but is owes parts of its popularity to its application to NLP problems other than NLG, e.g., machine translation and semantic parsing.
Seccomp
seccomp (short for secure computing) is a computer security facility in the Linux kernel. seccomp allows a process to make a one-way transition into a "secure" state where it cannot make any system calls except exit(), sigreturn(), read() and write() to already-open file descriptors. Should it attempt any other system calls, the kernel will either just log the event or terminate the process with SIGKILL or SIGSYS. In this sense, it does not virtualize the system's resources but isolates the process from them entirely. seccomp mode is enabled via the prctl(2) system call using the PR_SET_SECCOMP argument, or (since Linux kernel 3.17) via the seccomp(2) system call. seccomp mode used to be enabled by writing to a file, /proc/self/seccomp, but this method was removed in favor of prctl(). In some kernel versions, seccomp disables the RDTSC x86 instruction, which returns the number of elapsed processor cycles since power-on, used for high-precision timing. seccomp-bpf is an extension to seccomp that allows filtering of system calls using a configurable policy implemented using Berkeley Packet Filter rules. It is used by OpenSSH and vsftpd as well as the Google Chrome/Chromium web browsers on ChromeOS and Linux. (In this regard seccomp-bpf achieves similar functionality, but with more flexibility and higher performance, to the older systrace—which seems to be no longer supported for Linux.) Some consider seccomp comparable to OpenBSD pledge(2) and FreeBSD capsicum(4). == History == seccomp was first devised by Andrea Arcangeli in January 2005 for use in public grid computing and was originally intended as a means of safely running untrusted compute-bound programs. It was merged into the Linux kernel mainline in kernel version 2.6.12, which was released on March 8, 2005. == Software using seccomp or seccomp-bpf == Android uses a seccomp-bpf filter in the zygote since Android 8.0 Oreo. systemd's sandboxing options are based on seccomp. QEMU, the Quick Emulator, the core component to the modern virtualization together with KVM uses seccomp on the parameter --sandbox Docker – software that allows applications to run inside of isolated containers. Docker can associate a seccomp profile with the container using the --security-opt parameter. Arcangeli's CPUShare was the only known user of seccomp for a while. Writing in February 2009, Linus Torvalds expresses doubt whether seccomp is actually used by anyone. However, a Google engineer replied that Google is exploring using seccomp for sandboxing its Chrome web browser. Firejail is an open source Linux sandbox program that utilizes Linux namespaces, Seccomp, and other kernel-level security features to sandbox Linux and Wine applications. As of Chrome version 20, seccomp-bpf is used to sandbox Adobe Flash Player. As of Chrome version 23, seccomp-bpf is used to sandbox the renderers. Snap specify the shape of their application sandbox using "interfaces" which snapd translates to seccomp, AppArmor and other security constructs vsftpd uses seccomp-bpf sandboxing as of version 3.0.0. OpenSSH has supported seccomp-bpf since version 6.0. Mbox uses ptrace along with seccomp-bpf to create a secure sandbox with less overhead than ptrace alone. LXD, a Ubuntu "hypervisor" for containers Firefox and Firefox OS, which use seccomp-bpf Tor supports seccomp since 0.2.5.1-alpha Lepton, a JPEG compression tool developed by Dropbox uses seccomp Kafel is a configuration language, which converts readable policies into seccompb-bpf bytecode Subgraph OS uses seccomp-bpf Flatpak uses seccomp for process isolation Bubblewrap is a lightweight sandbox application developed from Flatpak minijail uses seccomp for process isolation SydBox uses seccomp-bpf to improve the runtime and security of the ptrace sandboxing used to sandbox package builds on Exherbo Linux distribution. File, a Unix program to determine filetypes, uses seccomp to restrict its runtime environment Zathura, a minimalistic document viewer, uses seccomp filter to implement different sandbox modes Tracker, a indexing and preview application for the GNOME desktop environment, uses seccomp to prevent automatic exploitation of parsing vulnerabilities in media files
IT baseline protection
The IT baseline protection (German: IT-Grundschutz) approach from the German Federal Office for Information Security (BSI) is a methodology to identify and implement computer security measures in an organization. The aim is the achievement of an adequate and appropriate level of security for IT systems. To reach this goal the BSI recommends "well-proven technical, organizational, personnel, and infrastructural safeguards". Organizations and federal agencies show their systematic approach to secure their IT systems (e.g. Information Security Management System) by obtaining an ISO/IEC 27001 Certificate on the basis of IT-Grundschutz. == Overview baseline security == The term baseline security signifies standard security measures for typical IT systems. It is used in various contexts with somewhat different meanings. For example: Microsoft Baseline Security Analyzer: Software tool focused on Microsoft operating system and services security Cisco security baseline: Vendor recommendation focused on network and network device security controls Nortel baseline security: Set of requirements and best practices with a focus on network operators ISO/IEC 13335-3 defines a baseline approach to risk management. This standard has been replaced by ISO/IEC 27005, but the baseline approach was not taken over yet into the 2700x series. There are numerous internal baseline security policies for organizations, The German BSI has a comprehensive baseline security standard, that is compliant with the ISO/IEC 27000-series == BSI IT baseline protection == The foundation of an IT baseline protection concept is initially not a detailed risk analysis. It proceeds from overall hazards. Consequently, sophisticated classification according to damage extent and probability of occurrence is ignored. Three protection needs categories are established. With their help, the protection needs of the object under investigation can be determined. Based on these, appropriate personnel, technical, organizational and infrastructural security measures are selected from the IT Baseline Protection Catalogs. The Federal Office for Security in Information Technology's IT Baseline Protection Catalogs offer a "cookbook recipe" for a normal level of protection. Besides probability of occurrence and potential damage extents, implementation costs are also considered. By using the Baseline Protection Catalogs, costly security analyses requiring expert knowledge are dispensed with, since overall hazards are worked with in the beginning. It is possible for the relative layman to identify measures to be taken and to implement them in cooperation with professionals. The BSI grants a baseline protection certificate as confirmation for the successful implementation of baseline protection. In stages 1 and 2, this is based on self declaration. In stage 3, an independent, BSI-licensed auditor completes an audit. Certification process internationalization has been possible since 2006. ISO/IEC 27001 certification can occur simultaneously with IT baseline protection certification. (The ISO/IEC 27001 standard is the successor of BS 7799-2). This process is based on the new BSI security standards. This process carries a development price which has prevailed for some time. Corporations having themselves certified under the BS 7799-2 standard are obliged to carry out a risk assessment. To make it more comfortable, most deviate from the protection needs analysis pursuant to the IT Baseline Protection Catalogs. The advantage is not only conformity with the strict BSI, but also attainment of BS 7799-2 certification. Beyond this, the BSI offers a few help aids like the policy template and the GSTOOL. One data protection component is available, which was produced in cooperation with the German Federal Commissioner for Data Protection and Freedom of Information and the state data protection authorities and integrated into the IT Baseline Protection Catalog. This component is not considered, however, in the certification process. == Baseline protection process == The following steps are taken pursuant to the baseline protection process during structure analysis and protection needs analysis: The IT network is defined. IT structure analysis is carried out. Protection needs determination is carried out. A baseline security check is carried out. IT baseline protection measures are implemented. Creation occurs in the following steps: IT structure analysis (survey) Assessment of protection needs Selection of actions Running comparison of nominal and actual. === IT structure analysis === An IT network includes the totality of infrastructural, organizational, personnel, and technical components serving the fulfillment of a task in a particular information processing application area. An IT network can thereby encompass the entire IT character of an institution or individual division, which is partitioned by organizational structures as, for example, a departmental network, or as shared IT applications, for example, a personnel information system. It is necessary to analyze and document the information technological structure in question to generate an IT security concept and especially to apply the IT Baseline Protection Catalogs. Due to today's usually heavily networked IT systems, a network topology plan offers a starting point for the analysis. The following aspects must be taken into consideration: The available infrastructure, The organizational and personnel framework for the IT network, Networked and non-networked IT systems employed in the IT network. The communications connections between IT systems and externally, IT applications run within the IT network. === Protection needs determination === The purpose of the protection needs determination is to investigate what protection is sufficient and appropriate for the information and information technology in use. In this connection, the damage to each application and the processed information, which could result from a breach of confidentiality, integrity or availability, is considered. Important in this context is a realistic assessment of the possible follow-on damages. A division into the three protection needs categories "low to medium", "high" and "very high" has proved itself of value. "Public", "internal" and "secret" are often used for confidentiality. === Modelling === Heavily networked IT systems typically characterize information technology in government and business these days. As a rule, therefore, it is advantageous to consider the entire IT system and not just individual systems within the scope of an IT security analysis and concept. To be able to manage this task, it makes sense to logically partition the entire IT system into parts and to separately consider each part or even an IT network. Detailed documentation about its structure is prerequisite for the use of the IT Baseline Protection Catalogs on an IT network. This can be achieved, for example, via the IT structure analysis described above. The IT Baseline Protection Catalogs' components must ultimately be mapped onto the components of the IT network in question in a modelling step. === Baseline security check === The baseline security check is an organisational instrument offering a quick overview of the prevailing IT security level. With the help of interviews, the status quo of an existing IT network (as modelled by IT baseline protection) relative to the number of security measures implemented from the IT Baseline Protection Catalogs are investigated. The result is a catalog in which the implementation status "dispensable", "yes", "partly", or "no" is entered for each relevant measure. By identifying not yet, or only partially, implemented measures, improvement options for the security of the information technology in question are highlighted. The baseline security check gives information about measures, which are still missing (nominal vs. actual comparison). From this follows what remains to be done to achieve baseline protection through security. Not all measures suggested by this baseline check need to be implemented. Peculiarities are to be taken into account! It could be that several more or less unimportant applications are running on a server, which have lesser protection needs. In their totality, however, these applications are to be provided with a higher level of protection. This is called the (cumulation effect). The applications running on a server determine its need for protection. Several IT applications can run on an IT system. When this occurs, the application with the greatest need for protection determines the IT systems protection category. Conversely, it is conceivable that an IT application with great protection needs does not automatically transfer this to the IT system. This may happen because the IT system is configured redundantly, or because only an inconsequential part is running on it. This is called the (distribution effect). This is the case, fo
Computer Law & Security Review
The Computer Law & Security Review is an international peer-reviewed journal published by Elsevier. It has been published six times a year since 1985 and is indexed in Scopus and SSCI. It is accessible to a wide range of professional legal and IT practitioners, businesses, academics, researchers, libraries and organisations in both the public and private sectors. The journal regularly covers: CLSR Briefing with special emphasis on UK/US developments European Union update National news from 10 European jurisdictions Pacific rim news column Refereed practitioner and academic papers on topics such as Web 2.0, IT security, Identity management, ID cards, RFID, interference with privacy, Internet law, telecoms regulation, online broadcasting, intellectual property, software law, e-commerce, outsourcing, data protection and freedom of information and many other topics. The Journal's Correspondent Panel includes more than 40 specialists in IT law and security. Each issue contains articles, case law analysis and current news on information and communications technology. Special Features High quality peer reviewed papers from internationally renowned practitioner and academic experts Latest developments reported in situ by more than 20 leading law firms from around the world Highly experienced and respected editor and correspondents panel Online access to all 23 volumes of CLSR with embedded web links to primary sources Contact details of all authors A pool of expertise that can collectively identify the key topics that need to be examined.
Display list
A display list, also called a command list in Direct3D 12 and a command buffer in Vulkan, is a series of graphics commands or instructions that are run when the list is executed. Systems that make use of display list functionality are called retained mode systems, while systems that do not are as opposed to immediate mode systems. In OpenGL, display lists are useful to redraw the same geometry or apply a set of state changes multiple times. This benefit is also used with Direct3D 12's bundle command lists. In Direct3D 12 and Vulkan, display lists are regularly used for per-frame recording and execution. == Origins in vector displays == The vector monitors or calligraphic displays of the 1960s and 1970s used electron beam deflection to draw line segments, points, and sometimes curves directly on a CRT screen. Because the image would immediately fade, it needed to be redrawn many times a second (storage tube CRTs retained the image until blanked, but they were unsuitable for interactive graphics). To refresh the display, a dedicated CPU called a Display Processor or Display Processing Unit (DPU) was used, which had a memory buffer for a "display list", "display file", or "display program" containing line segment coordinates and other information. Advanced Display Processors also supported control flow instructions, which were useful for drawing repetitive graphics such as text, and some could perform coordinate transformations such as 3D projection. == Home computer display list functionality == One of the earliest systems with a true display list was the Atari 8-bit computers. The display list (actually called so in Atari terminology) is a series of instructions for ANTIC, the video co-processor used in these machines. This program, stored in the computer's memory and executed by ANTIC in real-time, can specify blank lines, any of six text modes and eight graphics modes, which sections of the screen can be horizontally or vertically fine-scrolled, and trigger Display List Interrupts (called raster interrupts or HBI on other systems). The Amstrad PCW family contains a Display List function called the 'Roller RAM'. This is a 512-byte RAM area consisting of 256 16-bit pointers in RAM, one for each line of the 720 × 256 pixel display. Each pointer identifies the location of 90 bytes of monochrome pixels that hold the line's 720 pixel states. The 90 bytes of 8 pixel states are spaced at 8-byte intervals, so there are 7 unused bytes between each byte of pixel data. This suits how the text-orientated PCW constructs a typical screen buffer in RAM, where the first character's 8 rows are stored in the first 8 bytes, the second character's rows in the next 8 bytes, and so on. The Roller RAM was implemented to speed up display scrolling as it would have been unacceptably slow for its 3.4 MHz Z80 to move up the 23 KB display buffer 'by hand' i.e. in software. The Roller RAM starting entry used at the beginning of a screen refresh is controlled by a Z80-writable I/O register. Therefore, the screen can be scrolled simply by changing this I/O register. Another system using a Display List-like feature in hardware is the Amiga, which, not coincidentally, was also designed by some of the same people who developed the custom hardware for the Atari 8-bit computers. Once directed to produce a display mode, it would continue to do so automatically for every following scan line. The computer also included a dedicated co-processor, called "Copper", which ran a simple program or 'Copper List' intended for modifying hardware registers in sync with the display. The Copper List instructions could direct the Copper to wait for the display to reach a specific position on the screen, and then change the contents of hardware registers. In effect, it was a processor dedicated to servicing raster interrupts. The Copper was used by Workbench to mix multiple display modes (multiple resolutions and color palettes on the monitor at the same time), and by numerous programs to create rainbow and gradient effects on the screen. The Amiga Copper was also capable of reconfiguring the sprite engine mid-frame, with only one scanline of delay. This allowed the Amiga to draw more than its 8 hardware sprites, so long as the additional sprites did not share scanlines (or the one scanline gap) with more than 7 other sprites. i.e., so long as at least one sprite had finished drawing, another sprite could be added below it on the screen. Additionally, the later 32-bit AGA chipset allowed the drawing of bigger sprites (more pixels per row) while retaining the same multiplexing. The Amiga also had dedicated block-shifter ("blitter") hardware, which could draw larger objects into a framebuffer. This was often used in place of, or in addition to, sprites. In more primitive systems, the results of a display list can be simulated, though at the cost of CPU-intensive writes to certain display modes, color control, or other visual effect registers in the video device, rather than a series of rendering commands executed by the device. Thus, one must create the displayed image using some other rendering process, either before or while the CPU-driven display generation executes. In many cases, the image is also modified or re-rendered between frames. The image is then displayed in various ways, depending on the exact way in which the CPU-driven display code is implemented. Examples of the results possible on these older machines requiring CPU-driven video include effects such as Commodore 64/128's FLI mode, or Rainbow Processing on the ZX Spectrum. == Usage in OpenGL == To delimit a display list, the glNewList and glEndList functions are used, and to execute the list, the glCallList function is used. Almost all rendering commands that occur between the function calls are stored in the display list. Commands that affect the client state are not stored in display lists. Display lists are named with an integer value, and creating a display list with the same name as one already created overrides the first. The glNewList function expects two arguments: an integer representing the name of the list, and an enumeration for the compilation mode. The two modes include GL_COMPILE_AND_EXECUTE, which compiles and immediately executes, and GL_COMPILE, which only compiles the list. Display lists enable the use of the retained mode rendering pattern, which is a system in which graphics commands are recorded (retained) to execute in succession at a later time. This is contrary to immediate mode, where graphics commands are immediately executed on client calls. == Usage in Direct3D 12 == Command lists are created using the ID3D12Device::CreateCommandList function. Command lists may be created in several types: direct, bundle, compute, copy, video decode, video process, and video encoding. Direct command lists specify that a command list the GPU can execute, and doesn't inherit any GPU state. Bundles, are best used for storing and executing small sets of commands any number of times. This is used differently than regular command lists, where commands stored in a command list are typically executed only once. Compute command lists are used for general computations, with a common use being calculating mipmaps. A copy command list is strictly for copying and the video decode and video process command lists are for video decoding and processing respectively. Upon creation, command lists are in the recording state. Command lists may be re-used by calling the ID3D12GraphicsCommandList::Reset function. After recording commands, the command list must be transitioned out of the recording state by calling ID3D12GraphicsCommandList::Close. The command list is then executed by calling ID3D12CommandQueue::ExecuteCommandLists.
Clipping (computer graphics)
Clipping, in the context of computer graphics, is a method to selectively enable or disable rendering operations within a defined region of interest. Mathematically, clipping can be described using the terminology of constructive geometry. A rendering algorithm only draws pixels in the intersection between the clip region and the scene model. Lines and surfaces outside the view volume (aka. frustum) are removed. Clip regions are commonly specified to improve render performance. Pixels that will be drawn are said to be within the clip region. Pixels that will not be drawn are outside the clip region. More informally, pixels that will not be drawn are said to be "clipped." == In 2D graphics == In two-dimensional graphics, a clip region may be defined so that pixels are only drawn within the boundaries of a window or frame. Clip regions can also be used to selectively control pixel rendering for aesthetic or artistic purposes. In many implementations, the final clip region is the composite (or intersection) of one or more application-defined shapes, as well as any system hardware constraints In one example application, consider an image editing program. A user application may render the image into a viewport. As the user zooms and scrolls to view a smaller portion of the image, the application can set a clip boundary so that pixels outside the viewport are not rendered. In addition, GUI widgets, overlays, and other windows or frames may obscure some pixels from the original image. In this sense, the clip region is the composite of the application-defined "user clip" and the "device clip" enforced by the system's software and hardware implementation. Application software can take advantage of this clip information to save computation time, energy, and memory, avoiding work related to pixels that aren't visible. == In 3D graphics == In three-dimensional graphics, the terminology of clipping can be used to describe many related features. Typically, "clipping" refers to operations in the plane that work with rectangular shapes, and "culling" refers to more general methods to selectively process scene model elements. This terminology is not rigid, and exact usage varies among many sources. Scene model elements include geometric primitives: points or vertices; line segments or edges; polygons or faces; and more abstract model objects such as curves, splines, surfaces, and even text. In complicated scene models, individual elements may be selectively disabled (clipped) for reasons including visibility within the viewport (frustum culling); orientation (backface culling), obscuration by other scene or model elements (occlusion culling, depth- or "z" clipping). Sophisticated algorithms exist to efficiently detect and perform such clipping. Many optimized clipping methods rely on specific hardware acceleration logic provided by a graphics processing unit (GPU). The concept of clipping can be extended to higher dimensionality using methods of abstract algebraic geometry. === Near clipping === Beyond projection of vertices & 2D clipping, near clipping is required to correctly rasterise 3D primitives; this is because vertices may have been projected behind the eye. Near clipping ensures that all the vertices used have valid 2D coordinates. Together with far-clipping it also helps prevent overflow of depth-buffer values. Some early texture mapping hardware (using forward texture mapping) in video games suffered from complications associated with near clipping and UV coordinates. === Occlusion clipping (Z- or depth clipping) === In 3D computer graphics, "Z" often refers to the depth axis in the system of coordinates centered at the viewport origin: "Z" is used interchangeably with "depth", and conceptually corresponds to the distance "into the virtual screen." In this coordinate system, "X" and "Y" therefore refer to a conventional cartesian coordinate system laid out on the user's screen or viewport. This viewport is defined by the geometry of the viewing frustum, and parameterizes the field of view. Z-clipping, or depth clipping, refers to techniques that selectively render certain scene objects based on their depth relative to the screen. Most graphics toolkits allow the programmer to specify a "near" and "far" clip depth, and only portions of objects between those two planes are displayed. A creative application programmer can use this method to render visualizations of the interior of a 3D object in the scene. For example, a medical imaging application could use this technique to render the organs inside a human body. A video game programmer can use clipping information to accelerate game logic. For example, a tall wall or building that occludes other game entities can save GPU time that would otherwise be spent transforming and texturing items in the rear areas of the scene; and a tightly integrated software program can use this same information to save CPU time by optimizing out game logic for objects that aren't seen by the player. == Algorithms == Line clipping algorithms: Cohen–Sutherland Liang–Barsky Fast-clipping Cyrus–Beck Nicholl–Lee–Nicholl Skala O(lg N) algorithm Polygon clipping algorithms: Greiner–Hormann Sutherland–Hodgman Weiler–Atherton Vatti Rendering methodologies Painter's algorithm
